Manufacturing and Testing to Industry Standards for Network Applications

The pressure is on for design engineers and manufacturers to develop new, quality products to function in broadband and wireless networks. To maintain a business’ reputation, it is crucial to enact strict processes to ensure products meet and exceed customer expectations. This can be done through product testing, which guarantees a quality solution by conforming to recognized industry standards.

In this blog, we explore available testing methods and important quality standards to meet, as well as the potential consequences if product assessments are not completed.

Product Defects Pose Risks to Customers

Defects are any characteristic that hinders a product’s effect on customer usability. Even upon intended use, device defects can lead to serious injuries to an installer or a customer. Additionally, a single defective product can cause an avalanche of errors within a network, facilitating poor quality for a subscriber.

What are the best ways to avoid these shortcomings? Rigorously test products to confirm quality. Below are some conventional tests that can be used to guarantee products align with industry requirements and expectations to support broadband network architectures:

• High Potential Test (Hipot) - Necessary for hardline adapters and terminators, this test ensures current flows without failure. The assessment verifies reliability by properly insulating circuits and guaranteeing operational safety. Without appropriate electrical isolation, serious injury may occur.
• Electrostatic Discharge Test (ESD) - Have you ever wondered why you’ve been shocked by a doorknob? That’s because you’ve been charged with static electricity, and once you touch a conductive surface, a spark – called electrostatic discharge – occurs. For sensitive electronic devices, this spark can cause permanent product damage. The ESD test evaluates the stability of electronic devices when electrostatic discharge occurs. This test assesses whether these devices will be damaged by this unexpected occurrence.
• Surge Test - This test subjects a system to voltage spikes on top of the nominal voltage input. These peaks represent voltage fluctuations from events such as a lightning strike. This test certifies the equipment is protected and continues to perform, even if a surge occurs. Surge testing is critical for splitters, couplers, ground blocks and power supplies.
• Underwriters Laboratories (UL) Tests – UL, a global safety science leader, provides expertise in advisory and risk management, certifications, inspections, testing, and more. To streamline the safety of customers, UL confirms products align with applicable requirements and expectations through rigorous testing processes, much like the previously described tests.

Durability Throughout a Product’s Lifetime

Throughout a product’s lifespan, there are several conditions that can break down the product’s effectiveness and hinder performance. When determining safety for product use, it is critical to understand potential influences such as environmental factors or pressure loading. Consider applying these four endurance assessments when testing fiber and copper products:

1. Environmental Aging - Conducted to simulate extreme environmental conditions by designing a temperature and humidity cycling profile based on each product’s specific requirements, and monitoring performance over a specified number of completed cycles.
2. Moisture Ingress Testing - Real life weather survival of outdoor products is gauged by immersion in a red dye solution with temperature cycles, followed by dissection and microscopic examination for evidence of red dye ingress.
3. Pull Strength - Confirming the ability of product material to withstand pulling force by measuring breaking strength, elongation, pull force and more.
4. Temperature Cycling - Verifies product performance against repeated cycles from -40 °F (-40°C) to 185 °F (85°C) with a quick transition between temperature extremes.

Understanding Network Level Functions

In a broadband or wireless system, a valuable solution creates no conflicts within the network. It is vital to test individual products in the type of systems where it will function to guarantee a healthy network application, including:

• Optical Performance – Consists of two major assessments: insertion loss and return loss. These tests, commonly conducted on fiber optic cable assemblies and filters, determine if connections are properly mated and do not cause loss of signal throughout a system.
• Radio Frequency Interference (RFI) - Commercial or residential devices can radiate RFI, and devices that absorb RFI may fail or degrade in performance. The RFI test checks whether a device is sufficiently shielded against interference absorption and confirms it is not radiating RFI. These RFI tests can be completed on coaxial products, such as drop cables and connectors, hardline cables and connectors, adapters, filters, splitters, couplers, terminators, amplifiers, and power supplies.
